To turn off corner treatments, right-click Flat-Pattern1, and select Edit Feature. In the PropertyManager, clear Corner treatment. Here is an example of corner treatments: Search 'Corner Treatments' in the SOLIDWORKS Knowledge Base. SOLIDWORKS welcomes your feedback concerning the presentation, accuracy, and thoroughness of the documentation.
Full Answer
How do you apply a corner treatment in Solidworks?
Right-click a structural member in the FeatureManager design tree and select Edit Feature. Click the corner you want to modify. In the Corner Treatment dialog box, work with the highlighted group, Group 1. If additional groups meet at this corner, you can select another group from the groups that are listed.
How do I enable Weldments in SOLIDWORKS?
Click Structural Member (Weldments toolbar) or Insert > Weldments > Structural Member . Make selections in the PropertyManager to define the profile for the structural member. In the graphics area, select sketch segments to define the path for the structural member.
How to see Weldments in SOLIDWORKS?
To do so, right-click on the Tabs area in the CommandManager to access this menu and select Weldments.
How does SOLIDWORKS Weldment work?
You can use 2D and 3D sketches to define the basic framework of a weldment structure, then create structural members containing groups of sketch segments. You can also add items such as gussets and end caps using tools on the Weldments toolbar.
How do you add weldments in SOLIDWORKS 2020?
Additional weldment profiles are available on the Design Library tab . Under SOLIDWORKS Content , in the Weldments folder, Ctrl + click items to download ....Weldments - Creating a Custom ProfileOpen a new part.Sketch a profile. ... Close the sketch.In the FeatureManager design tree, select Sketch1.Click File > Save As.More items...
How do you add weldments in SOLIDWORKS 2018?
In a part, click Weld Bead (Weldments toolbar) or Insert > Weldments > Weld Bead . In an assembly, click Insert > Assembly Feature > Weld Bead . In the graphics area, select the faces or edges for the weld bead. Alternatively, use the Smart Weld Selection Tool to make selections.
What is a weldments?
Definition of weldment : a unit formed by welding together an assembly of pieces.
How do I add a weldment profile in SOLIDWORKS?
Set the SOLIDWORKS file path to look in the location where you're creating your profiles. To do this, go to System Options. Change the “Show folders for” drop-down menu to Weldment Profiles. Select the Add button.
How do I show weld bead in SOLIDWORKS assembly?
Weld Beads in AssembliesClick Assembly Features (Assembly tab on the CommandManager) and click Weld Bead .Click Insert > Assembly Feature > Weld Bead.Click Weld Bead (Weldments toolbar).
How do I edit my weldment profile?
Updating the nameOpen the weldment profile that you wish to modify using the SOLIDWORKS file explorer.Open the Custom Property Window for the profile and modify the text within the Description row. ... Once the name change has been made click OK and save the weldment profile.More items...•
Where are SOLIDWORKS weldment profiles stored?
install_dir \lang\ language \weldment profilesThe default location for weldment profiles is install_dir \lang\ language \weldment profiles. You can file your custom profile in the folder structure that SOLIDWORKS provides, or you can create a separate folder structure.
How do you make weldments?
0:292:39How To Create Custom SOLIDWORKS Weldment ProfilesYouTubeStart of suggested clipEnd of suggested clipBest practice here is to save your custom profiles. Or really any custom template in a separateMoreBest practice here is to save your custom profiles. Or really any custom template in a separate folder outside the default SolidWorks installation this makes creating backups of your custom data.
