Full Answer
How do you get rid of phosphorus in wastewater?
Phosphorus Removal 1 Approaches to Phosphorus Removal in Wastewater. As phosphorus issues persist, regulations that limit levels in wastewater will become more strict. ... 2 Physical Treatment. ... 3 Chemical Treatment. ... 4 Biological Treatment. ...
How much phosphorous is removed from water?
This process is usually quite slow. Normally secondary treatment can only remove 1-2 mg/l, so a large excess of phosphorous is discharged in the final effluent, causing eutrophication in surface waters. New legislation requires a maximum concentration of P discharges into sensitive water of 2 mg/l.
What is the maximum concentration of phosphorous in wastewater treatment?
New legislation requires a maximum concentration of P discharges into sensitive water of 2 mg/l. The removal of phosphorous from wastewater involves the incorporation of phosphate into TSS and the subsequent removal from these solids.
What are the main phosphate removal processes?
The main phosphate removal processes are (see picture below): 1 Treatment of raw/primary wastewater 2 Treatment of final effluent of biological plants (postprecipitation) 3 Treatment contemporary to the secondary biologic reaction (co-precipitation).
See more
How much amount of phosphorus is removed by secondary treatment?
Therefore, primary and secondary wastewater treatment can removes about 20-30% of phosphorus, and phosphorus content in pre-treated water is high above standard regulated limits.
What is the permissible level of phosphorus in wastewater?
An effluent limitation equal to 1 mg/L total phosphorus as a monthly average shall apply in cases where the discharge of wastewater from all outfalls of a facility other than those subject to ch.
How much amount of phosphorus is removed by secondary treatment in mg L?
1-2 mg/lNormally secondary treatment can only remove 1-2 mg/l, so a large excess of phosphorous is discharged in the final effluent, causing eutrophication in surface waters. New legislation requires a maximum concentration of P discharges into sensitive water of 2 mg/l.
How do wastewater treatment plants remove phosphorus?
Phosphorus removal from wastewater can be achieved either through chemical removal, advanced biological treatment or a combination of both. The chemical removal of phosphorus involves the addition of calcium, iron and aluminium salts to achieve phosphorus precipitation by various mechanisms which are discussed.
What is a good level of phosphorus in water?
Regulation: In 1986, the Environmental Protection Agency (EPA) established the following recommended criteria for phosphorus: No more than 0.1 mg/L for streams that do not empty into reservoirs; no more than 0.05 mg/L for streams discharging into reservoirs; and no more than 0.024 mg/L for reservoirs.
What are the unsafe levels of phosphates?
Phosphates are not toxic to people or animals unless they are present in very high levels, i.e., > 1000 mg/L.
What is the percentage of sludge in phosphorus removal by chemical precipitation?
2. What is the percentage of sludge in phosphorus removal by chemical precipitation? Explanation: Phosphate removal is currently achieved largely by chemical precipitation, which is expensive and causes an increase in sludge volume by up to 40%. 3.
Do water treatment plants remove phosphates?
Most wastewater treatment plants (WWTPs) use two strategies to remove phosphorus: chemical phosphorus removal (CPR) and biological phosphorus removal (BPR). Chemical phosphorus removal typically involves precipitating influent phosphorus with an iron or aluminum salt.
What is the percentage of phosphorus present in bacterial biomass?
Clarification: The percentage of phosphorous is 1-2 in all the bacterial biomass. A fraction of phosphorous is present in all the bacterial biomass.
Why does phosphorus need to be removed from wastewater?
The removal of phosphorus (P) from domestic wastewater is primarily to reduce the potential for eutrophication in receiving waters, and is mandated and common in many countries.
How is phosphorus removed from water?
Chemical treatment for phosphorus removal involves the addition of metal salts to react with soluble phosphate to form solid precipitates that are removed by solids separation processes including clarification and filtration.
What causes high phosphorus levels in wastewater?
High concentrations of phosphorus may result from poor agricultural practices, runoff from urban areas and lawns, leaking septic systems or discharges from sewage treatment plants.
What are the advantages of biological phosphorous removal?
The principal advantages of biological phosphorous removal are reduced chemical costs and less sludge production as compared to chemical precipitation . In the biological removal of phosphorous, the phosphorous in the influent wastewater is incorporated into cell biomass, which is subsequently removed from the process as a result of sludge wasting.
How does PHB increase in the aerobic zone?
In the aerobic zone: energy is produced by the oxidation of storage products and polyphosphate storage within the cell increases . Stored PHB is metabolized, providing energy from oxidation and carbon for new cell growth.
What is the phosphorous concentration in the final effluent?
The phosphorous concentration in the final effluent is about 1 mg/l. Another disadvantage is that biological and chemical sludge are mixed, so they cannot be used separately in next stages. Mixed sludges need bigger sedimentation tanks than activated sludge. Biological processes.
What is the reaction of ferric chloride and copperas?
The basic reaction is: Fe 3+ + H n PO 43-n ↔ FePO 4 + nH +. Ferric ions combine to form ferric phosphate.
What is the chemical precipitation of phosphate?
Chemical precipitation is used to remove the inorganic forms of phosphate by the addition of a coagulant and a mixing of wastewater and coagulant. The multivalent metal ions most commonly used are calcium, aluminium and iron. Calcium: it is usually added in the form of lime Ca (OH) 2.
What are the processes of phosphate removal?
The main phosphate removal processes are (see picture below): 1 Treatment of raw/primary wastewater 2 Treatment of final effluent of biological plants (postprecipitation) 3 Treatment contemporary to the secondary biologic reaction (co-precipitation).
What is the difference between orthophosphate and polyphosphate?
Usually polyphosphates undergo hydrolysis and revert to the orthophosphate forms.
How much phosphorus can be recovered from influent wastewater?
However, only around 50% of phosphorus can be recovered from influent wastewater because of the efficiency losses at EBPR and inefficient struvite crystallization under an imbalanced N/P ratio, leaving abundant amounts of unrecovered nitrogen in the centrate.
How is phosphorus removed from wastewater?
Phosphorus can usually be removed from municipal wastewater by enhanced biological phosphorus removal method. This process is operated in an anaerobic/aerobic condition via the enrichment of phosphorus-accumulating organisms (PAOs).
What is the environmental aspect?
The environmental aspect consists of the effect on nitrogen and phosphorus removal, effect on sludge treatment, and occupied land. The technological dimension is measured according to stability, maturity, and operability. The social aspect includes only one criterion, namely social acceptability.
When was the MBR invented?
The earliest reports of MBRs come from the late 1960s. At that time, Dorr-Oliver, Inc. developed the membrane sewage-treatment process, in which wastewater flowed through a suspended growth bioreactor via rotating drum screen to externally located UF membrane modules. Concurrently, Thetford Systems, now part of Zenon Environmental, debuted an external MBR, dubbed the Cycle-Let, for domestic wastewater treatment. The company continued developing the MBR for industrial wastewater throughout the 1980s and 1990s, eventually securing two early patents and succeeded its commercialization in 1982. Now Zenon became a part of General Electric since 2007.
What is the process of removing phosphorus?
Phosphorus removal can be performed at different stages in the treatment process: prior to, simultaneous with, or after the biological step, and are hence called preprecipitation, coprecipitation, or postprecipitation, respectively .
What is the triple bottom line?
The “triple bottom line” is used to measure sustainability, which consists of three dimensions including people, planet, and profits referring to social aspects, environmental issues, and economic performances ( Hall, 2011; Piluso et al., 2010 ). Therefore the three sustainability dimensions are generally considered in the sustainability assessment criteria in many studies ( Moradi Aliabadi and Huang, 2016; Othman et al., 2010 ). However, since political criteria and technological criteria can significantly influence economic criteria and environmental criteria, policy and technology also play important roles in sustainability assessment ( Ren et al., 2015a,b ). This study proposed an evaluation criteria system composed of nine criteria (see Table 6.1) in terms of economy, environment, technology, and society to evaluate the sustainability of the alternative technologies for urban sewage treatment on the basis of literature reviews and focus group meetings, which seven experts participated in. These experts included three environmental engineering professors, one associate professor in sustainability engineering, two PhD students in Chemical Engineering, and one administrator from the local governmental sector, which is responsible for environment protection. They were invited to participate in the discussion to determine the sustainability assessment criteria system for alternative urban sewage treatment technologies.
Is phosphorus removal a process?
Although biological phosphorus removal is regarded as one of the most complex processes in wastewater treatment, it has become a reliable and effective method for nutrient removal through its widespread application in numerous WWT Ps. In this article, a summarizing historical overview of the process has been presented, as well as a concise review of the fundamentals and the current advances in the main biochemical and microbiological aspects. Emphasis was given to the denitrifying (anoxic) phosphorus removal, which seems to be a quite promising process in comparison with the conventional aerobic one, resulting in significant energy savings, improved efficiency, and stable EBPR performance. By integrating the growing scientific knowledge base with the practical applications in nutrient management, establishment of effective and reliable BNR processes can be assured.
Why Is Phosphorus a Problem in Wastewater?
While phosphorus is a necessary element, high levels of phosphorus can lead to multiple environmental complications in streams, lakes, rivers and coastal areas. A typical issue caused by elevated phosphorous in natural water sources is Eutrophication – a rampant stimulation of algae and other plants, leading to oxygen depletion in the water.
How Should Phosphorus be Removed from Wastewater?
There are several forms of phosphorus removal, the most effect effective system will depend on the characteristics of the wastewater, the existing infrastructure at treatment facility, and the effluent phosphorous level required. Project budget, operator maintenance, and form of phosphorous should also be taken into consideration.
Chemical vs. Biological Phosphorus Removal
Chemical phosphorus removal uses precipitating phosphors with an aluminum salt or iron salt. Iron salt, including ferric chloride, can provide numerous benefits to reduce scum in secondary treatment processes and manage orders and sulfides in anaerobically digest sludge.
Chemical Phosphorus Removal
Chemical phosphorus removal is a wastewater treatment process that uses iron, calcium or aluminum salts to remove phosphorus from the water. Phosphates create precipitates with metal ions and are removed with sludge in the separation unit.
Chemical System Options
There are numerous chemical systems that can remove phosphorus from water, including chemical dosing to promote p-precipitation, absorptive media for p-removal and ion exchange technologies.
Biological Phosphorus Removal
Biological phosphorus removal is a wastewater treatment process used to remove phosphorus from water. Biological phosphorus removal implementations use a group of heterotrophic bacteria to process excess phosphorus levels from water. Some of the main pros and cons of biological phosphorus removal include:
Biological System Options
Some of the most common biological system options include identification of PAO, metabolism of PAO, traditional enhanced biological phosphorus removal (EBPR), novel EBPR systems and potential EBPR systems.
How is phosphorus removed from wastewater?
The removal of phosphorous from wastewater involves the incorporation of phosphorus into the suspended solids within the plant and the subsequent removal of these solids.
What are the most common elements in the earth?
They are the most common of all of the rare earth elements. In the ground, cerium and lanthanum exist naturally in a mineral complex, most often in conjunction with phosphorus to which they are preferentially attracted. This cerium/lanthanum mineral is called rhabdophane.
What is phosphorus treatment?
Phosphorus Treatment. Controlling phosphorus discharged from wastewater treatment plants is a major factor in protecting surface waters. Phosphorous is one of the major nutrients contributing to the increased eutrophication of lakes and natural waters. Its presence causes many water quality problems including algal blooms, ...
What is used to remove phosphate?
Chemical precipitation is used to remove the inorganic forms of phosphate by the addition of a coagulant such as calcium, aluminum or iron. Traditional iron or aluminum metal salts are used but are less efficient in meeting today’s ultra-low phosphorus levels.
Why is rare earth better than phosphate?
Rare earth has a distinct chemical advantage over competing phosphate reduction products because of their natural affinity for elemental phosphorus. They will also remain bonded to the phosphorus during aerobic and anaerobic digestion, reducing the recycling of phosphorus back into the treatment plant.
Does rhabdophane precipitate settle?
Therefore, the rhabdophane precipitate settles rapidly during clarification.By comparison, aluminum and iron have lower molecular weights (27 and 55, respectively), and do not form strong molecular bonds with phosphorus. They are not as efficient in removing phosphorus from wastewater streams.
Do iron and aluminum coagulants bind to phosphorus?
Iron and aluminum-based coagulants do not bind to phosphorus very efficiently or tightly. They form intermediate metal hydroxides to which phosphate adsorbs onto the surface. This is a function of surface chemistry instead of a strong ionic bonding. The ratio of Fe or Al to phosphorus can be 4 to 1, or even higher.
